Dell Inspiron 7306 2-in-1 Silver User Manual

10. Adhere the tape that secures the I/O-board cable-latch to the system board.
11. Connect the speaker cable to the system board.
12. Connect the touchpad cable to the system board and close the latch.
13. Connect the keyboard-backlight cable from the system board and close the latch.
14. Connect the keyboard cable to the system board and close the latch.
15. Adhere the Mylar that secures the keyboard-cable latch to the system board.
16. Place the wireless-card bracket on the wireless card.
17. Replace the screw (M2x3) that secures the wireless-card bracket to the palm-rest assembly.
18. Close the right display-hinge.
NOTE: Ensure that the screw holes on the left display-hinge are aligned with the screw holes on the system board and
palm-rest assembly
19. Replace the screw (M2x5) that secures the right display-hinge to the palm-rest assembly.
20. Replace the screw (M2x3.5) that secures the right display-hinge to the system board and palm-rest assembly.
Next steps
1. Install the heat sink.
2. Install the fan.
3. Install the battery.
4. Install the M.2 2230 solid-state drive. (if applicable)
5. Install the M.2 2280 solid-state drive/Intel Optane H10. (if applicable)
6. Install the base cover.
7. Follow the procedure in After working inside your computer.
Palm-rest and keyboard assembly
Removing the palm-rest and keyboard assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the display assembly.
5. Remove the fan.
6. Remove the power-adapter port.
7. Remove the coin-cell battery.
8. Remove the I/O board.
9. Remove the touchpad.
10. Remove the speakers.
11. Remove the power-button with fingerprint reader.
12. Remove the system board.
NOTE: The system board can be removed along with the heat sink.
About this task
The following image(s) indicate the location of the palm-rest and keyboard assembly and provides a visual representation of the
removal procedure.
46
Removing and installing components

Dell Inspiron 7306 2-in-1 Silver Specifications

General

Graphics	Intel Iris Xe Graphics
Color	Silver
Webcam	720p at 30 fps HD camera
Audio	Stereo speakers with Waves MaxxAudio Pro
Processor	11th Generation Intel Core i7-1165G7
Display	13.3-inch FHD (1920 x 1080)
RAM	16GB LPDDR4x
Storage	512GB M.2 PCIe NVMe SSD
Operating System	Windows 10 Home
Battery	4-Cell, 53 WHr, Integrated battery
Wireless	Wi-Fi 6 (802.11ax), Bluetooth 5.1
Ports	1 x USB 3.2 Gen 1, 1 x HDMI 2.0, 1 x headphone/microphone combo jack
Dimensions	15.7 mm
