A Tour of Your Computer 27
Bottom View
SUBWOOFER Produces a broader bass output than is provided by the speakers.
BATTERY CHARGE GAUGE Provides information on the battery charge status. For more information, see
"Checking the Battery Charge" on page 44.
BATTERY-BAY LATCH RELEASE Releases the battery from the battery bay. For more information, see "Replacing
the Battery" on page 52.
BATTERY When a battery is installed, you can use the computer without connecting the computer to an
electrical outlet. For more information, see "Using a Battery" on page 43.
COVER FOR OPTIONAL INTERNAL CARD WITH BLUETOOTH
®
WIRELESS TECHNOLOGY For more information, see
the documentation that came with your card. To quickly enable or disable all wireless devices, press <Fn><F2>.
HARD DRIVE Stores software and data. For more information, see "Hard Drive" on page 119. The size displayed
for your hard drive in Windows Explorer is the capacity of the drive before any operating system or programs are
installed.
1 subwoofer 5 cover for optional internal
card with Bluetooth
®
wireless technology
9 memory module cover
2 battery charge gauge 6 hard drive 10 air vent
3 battery-bay latch release 7 air vent 11 optical-drive locking screw
4 battery 8 Mini-Card/modem cover
12 3 4
5
6
7
89
10
11
