14. Plug the fan cable into the FAN connector on the system board.
15. Plug the power cable into the 12VPOWER connector on the system board.
16. Close the computer cover.
17. Attach the computer stand (optional).

18. Connect your computer and devices to electrical outlets, and turn them on.
Back to Contents Page

1
heat-sink/blower assembly
4
retention base
2
screw
5
heat sink
3
retention base tab
6
screw
1
securing clip
2
tab
3
slot
4
retention base
NOTICE: To connect a network cable, first plug the cable into the network wall jack and then plug it into the computer.
