Next steps
1. Install the battery.
2. Install the base cover.
3. Follow the procedure in after working inside your computer.
Display assembly
Removing display assembly
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
Steps
1. Remove the single (M2.0x3.0) screw that secures the wireless bracket to the system board [1].
2. Lift the wireless bracket and disconnect the wireless antennas [2, 3].
46
Removing and Installing
