Replacing the power-adapter port
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-A3DB25AE-B77D-4A85-AAA2-026F8D8C69B0
Status Released
Procedure
1 Place the power-adapter port into the slot and adhere the power-adapter port on the palm rest and keyboard assembly.
2 Connect the power-adapter port cable to the system board.
3 Close the right hinge.
4 Replace the three screws (M2.5x6) that secure the right hinge to the system board and palm rest assembly.
24
Replacing the power-adapter port 51
