Replacing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Using the alignment posts, align and place the right speaker on the palm-rest and keyboard assembly.
NOTE: Ensure the rubber seals fit inside the grip of the alignment posts.
2. Route the speaker cable through the routing guides on the battery.
3. Using the alignment posts, align and place the left speaker on the palm-rest and keyboard assembly.
NOTE: Ensure the rubber seals fit inside the grip of the alignment posts.
4. Connect the speaker cable to the system board.
Post-requisites
Replace the base cover.
20
Replacing the speakers 35
