Dell Networking W-Series Wireless LAN Mobility Controller Optimizations for Microsoft Lync
4
Introduction
This guide focuses on system configurations required to ensure Quality of Service (QoS) for Microsoft
®
Lync
®
in a Dell W-Series Mobility controller-based deployment.
Media collaborative applications like Microsoft Lync providing voice, video, and instant messaging (IM)
are expected to reliably run across wireless LAN networks (WLANs) and provide the high quality of
service required by these applications. This guide outlines the steps needed to set up the Dell W-Series
controllers.
Configuration Settings
AOS Version
Dell W-series controllers must be running AOS 6.1.3.2 or higher.
AOS Version Figure 1.

Dell PowerConnect W-AP92 Specifications

Wireless Radio Specifications

supported frequency bands	2.400 to 2.4835 GHz, 5.150 to 5.850 GHz
transmit power 2.4 GHz	up to 23 dBm
transmit power 5 GHz	up to 23 dBm

Interfaces

ethernet interface	1 x 10/100/1000BASE-T Ethernet (RJ-45)
serial console interface	1 x RJ-45
power over ethernet	IEEE 802.3af Power over Ethernet (48V DC)

Power

external AC power	12V DC
maximum power consumption	10 watts
power over ethernet	48V DC

Operating Environment

operating temperature	0° to 50° C
operating humidity	5 to 95% non-condensing
storage temperature	-40° to 70° C

Weight and Dimensions

dimensions	120 mm x 130 mm x 35 mm
weight	375 g
antenna gain 2.4 GHz	2.5 dBi
