100 Installing System Components
1
Fit the I/O panel assembly so that the holding tab on the front of the
chassis catches at its bottom securing slot and the I/O panel assembly lines
up with the alignment stop. See Figure 3-30.
2
Secure the I/O panel assembly by replacing the screw. See Figure 3-30.
3
Secure the I/O panel ribbon cable through the clips beneath the
3.5 optional diskette drive and on the side of the power supply shroud, and
connect the I/O panel ribbon cable to the new I/O panel connector. See
Figure 3-31.
book.book Page 100 Wednesday, June 24, 2009 8:21 AM
