Dell PowerEdge R320 Technical Guide

22 PowerEdge R320 Technical Guide
Storage controllers
Dell provides highly capable RAID options for you to ensure that your data remains safe. Dell’s RAID
controller options offer impressive performance improvements, including the following features:
 FastPath™ I/O: This feature can help accelerate performance when operating on SSDs.
 Split mirror: This function allows you to break mirrored disk connection in order to quickly
replace a drive.
 Physical disk power management (Dimmer Switch™): This feature allows for power control of
spare or idle drives, which can save energy and operating expenses.
Supported RAID controllers
The newest line of PERC (PowerEdge RAID Controller) cards offers high I/O performance for
database applications and streaming digital media environments. The internal RAID controllers have
a dedicated connection to the system board. The R320 supports the new PERC 8 family of
controllers with improved functionality and faster performance.
The default PERC for the R320 is a mini-type PERC. The R320 also supports the new software RAID
solution that supports RAID 0, 1, 5 and 10. The R320 supports the PERC cards listed in Table 12. For
more information about the latest PERC offerings, see Dell.com/PERC.
Table 12. Supported RAID controllers
Controller
Description
Features
RAID
modes
supported
Form factor
Usage
model
PERC H810
External
8-port, external and 6Gb/s
PCIe RAID controller
Includes 1GB NV DDR3
cache, premium
performance and feature
set, security SED/EKMS,
and SSD as cache
0, 1, 10, 5,
50, 6, 60
Adapter
Premium
performance
PERC H710
Internal
8-port, internal 6Gb/s PCIe
RAID controller
Includes 512MB NV
DDR3 cache, advanced
feature set, security
SED/EKMS
0, 1, 10, 5,
50, 6, 60
Integrated
mini-type
Performance
PERC H310
Internal
8-port, internal 6Gb/s PCIe
RAID
Supports hot-plug
drives, expansion, pass-
through
0, 1, 10, 5,
50
Integrated
mini-type
Value
PERC S110
Software
RAID
3Gb/s SATA software RAID
controller that supports up
to 4 physical disks or 8
virtual disks
Supports up to four
hot-plug SATA drives, no
expansion, Microsoft
Windows only
0, 1, 5, 10
System
board-
embedded
SATA
Entry-level

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
