46 PowerEdge R320 Technical Guide
1.87 Grms at 10Hz to 500Hz for 15 minutes (all six sides tested)
Half sine shock in all operational orientations of 31G +/– 5% with a pulse duration of 2.6ms
+/– 10%
Half sine shock on all six sides of 71G +/– 5% with a pulse duration of 2ms +/–10%; square
wave shock on all six sides of 27G with velocity change at 235 in/sec or greater
–15.2m to 3048m (–50 ft to 10,000 ft)
–15.2m to 12,000m (–50 ft to 39,370 ft)
Airborne contaminant level
Class G1 or lower as defined by ISA-S71.04-1985
Power supply specifications
Table 27 lists power supply specifications for the PowerEdge R320.
Table 27. Power supply specifications
Heat dissipation
(BTU/hr max)
1
Auto-ranging
2
Under typical line conditions and over the entire system ambient operating range, the inrush current may reach 55A per
power supply for 10ms or less.
Rack rail specifications
Table 28 lists the spacing dimensions for the R320 sliding and static rails.
Table 28. Rail adjustability range
Rail adjustability range (mm)
The adjustment range of the rails is a function of the type of rack in which they are being mounted.
The min-max values listed above represent the allowable distance between the front and rear
mounting flanges in the rack. Rail depth without the CMA represents the minimum depth of the rails
with the outer CMA brackets removed (if applicable) as measured from the front mounting flanges
of the rack.
