Dell PowerEdge R320 Technical Guide

49 PowerEdge R320 Technical Guide
Appendix C. Additional resources
Table 30 provides a list of documents and websites that provide for more information on the Dell
PowerEdge R320.
Table 30. Additional resources
Resource
Description of contents
Location
Dell PowerEdge
R320 Systems
Owner’s Manual
This manual, available in PDF format, provides the
following information:
 Chassis features
 System Setup program
 System messages
 System codes and indicators
 System BIOS
 Remove and replace procedures
 Troubleshooting
 Diagnostics
 Jumpers and connectors
Dell.com/Support/Manuals
Dell PowerEdge
R320 Getting
Started Guide
This guide is printed and shipped with the system, and is
also available in PDF format on the Dell support site. This
guide provides information on the following:
 Initial setup steps
 Key system features
 Technical specifications
Dell.com/Support/Manuals
Rack Installation
Instructions
This printed document is provided with the rack kits. The
document provides the instructions for installing the
server in a rack.
Dell.com/Support/Manuals
Cable
Management Arm
Installation
Instructions
This printed document is provided with the CMA kits. The
document provides the instructions for installing the
cable management arm on the rails.
Dell.com/Support/Manuals
Information
Update
This document is printed and shipped with the system,
and is also available in PDF format on the Dell support
site. This document provides information on system
updates.
Dell.com/Support/Manuals
System
Information Label
The system information label documents the system
board layout and system jumper settings. Text is
minimized due to space limitations and translation
considerations. The label size is standardized across
platforms.
Inside the system chassis
cover
Quick Resource
Locator (QRL)
This code on the chassis can be scanned by a phone
application to access additional information and
resources for the server, including videos, reference
materials, service tag information and Dell contact
Inside the system chassis
cover

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
