Dell PowerEdge R510 User Manual

152 Installing System Components
5 Remove the front panel plate until it separates from the display module to
allow access to the mounting screws.
6 Remove the two screws that secures the display module to the system
chassis.
7 Remove the display module from the chassis cutout.
Installing the Control Panel Display Module
1 Insert the display module into the chassis cutout and secure with the Torx
screw. See Figure 3-32.
2 Attach the replacement panel to the front of the display module.
3 Connect the display module cable to the control panel board.
4 Close the system. See "Closing the System" on page 89.
5 Reconnect the system to the power source and turn on the system and
attached peripherals.
Removing the Control Panel Assembly
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 If installed, remove the front bezel. See "Removing the Front Bezel" on
page 86.
2 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet and peripherals.
3 Open the system. See "Opening the System" on page 87.
4 Disconnect the control panel cable at the back of the control panel board
by pressing the metal tabs on the ends of the cable connector and gently
working the connector out of the socket.
CAUTION: Do not pull on the cable to unseat the connector. Doing so can damage
the cable.
5 Disconnect the USB cable at the back of the control panel board. See
Figure 3-32.
book.book Page 152 Friday, November 20, 2009 2:56 PM

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
