Dell PowerVault MD3600i User Manual

Hardware Installation 25
Cabling PowerVault MD1200 Series Expansion
Enclosures
You can expand the capacity of your PowerVault MD3600i Series storage array
by adding PowerVault MD1200 Series expansion enclosures. You can expand
the physical disk pool to a maximum of 96 physical disks using a maximum of
seven expansion enclosures.
Expanding With Previously Configured PowerVault MD1200 Series
Expansion Enclosures
Use this procedure if your expansion enclosure is directly attached to and
configured on a Dell PERC H800 adapter. Data from virtual disks created on
a PERC H800 adapter cannot be directly migrated to a PowerVault MD3600i
Series storage array or to a PowerVault MD1200 Series expansion enclosure
connected to a PowerVault MD3600i Series storage array.
CAUTION: If a PowerVault MD1200 Series expansion enclosure that was
previously attached to PERC H800 adapter is used as an expansion enclosure to a
PowerVault MD3600i Series storage array, the physical disks of the expansion
enclosure are reinitialized and data is lost. You must backup all data on the
expansion enclosure before attempting the expansion.
To attach previously configured PowerVault MD1200 Series expansion
enclosures to the PowerVault MD3600i Series storage array:
1
Back up all data on the expansion enclosure(s).
2 While the enclosure is still attached to the PERC H800 controller,
upgrade the expansion enclosure firmware to the latest version
at
support.dell.com .
Windows systems users can reference the
DUP.exe package and Linux
kernel users can reference the
DUP.bin package.
book.book Page 25 Wednesday, December 29, 2010 9:23 PM
