Dell U2713HM User Manual

** Maximum power consumption with max luminance, Dell Soundbar, and USB active.
Pin Assignmentss
VGA Connector
Pin
Number
15-pin Side of the Connected Signal Cable
1 Video-Red
2 Video-Green
3 Video-Blue
4 GND
5 Self-test
6 GND-R
7 GND-G
8 GND-B
9 Computer 5 V/3.3 V
10 GND-sync
11 GND
12 DDC data
13 H-sync
14 V-sync
15 DDC clock
DVI Connector

Dell U2713HM Specifications

General

Screen Size	27 inches
Resolution	2560 x 1440
Panel Type	IPS
Aspect Ratio	16:9
Refresh Rate	60 Hz
Brightness	350 cd/m²
Display Colors	16.7 million
HDCP Support	Yes
Response Time	8 ms (gray to gray)
Contrast Ratio	1000:1
Viewing Angle	178°/178°
Color Gamut	99% sRGB
Ports	DisplayPort, HDMI, DVI-D, VGA, USB 3.0
Stand Adjustments	Height, Pivot, Swivel, Tilt
VESA Mount	100 mm x 100 mm
