Dell U2713HM User Manual

Adjusting the Rotation Display Settings of Your System
After you have rotated your monitor, you need to complete the procedure below to adjust the Rotation Display Settings of Your System.
NOTE: If you are using the monitor with a non-Dell computer, you need to go the graphics driver website or your computer manufacturer website for information on
rotating the 'contents' on your display.
To adjust the Rotation Display Settings:
1. Right-click on the desktop and click Properties.
2. Select the Settings tab and click Advanced.
3. If you have an ATI graphics card, select the Rotation tab and set the preferred rotation.
If you have an nVidia graphics card, click the nVidia tab, in the left-hand column select NVRotate, and then select the preferred rotation.
If you have an Intel
®
graphics card, select the Intel graphics tab, click Graphic Properties, select the Rotation tab, and then set the preferred rotation.
NOTE: If you do not see the rotation option or it is not working correctly, go to support.dell.com and download the latest driver for your graphics card.
Back to Contents Page

Dell U2713HM Specifications

General

Screen Size	27 inches
Resolution	2560 x 1440
Panel Type	IPS
Aspect Ratio	16:9
Refresh Rate	60 Hz
Brightness	350 cd/m²
Display Colors	16.7 million
HDCP Support	Yes
Response Time	8 ms (gray to gray)
Contrast Ratio	1000:1
Viewing Angle	178°/178°
Color Gamut	99% sRGB
Ports	DisplayPort, HDMI, DVI-D, VGA, USB 3.0
Stand Adjustments	Height, Pivot, Swivel, Tilt
VESA Mount	100 mm x 100 mm
