Dell U2713HM User Manual

Connecting the black DisplayPort cable (Optional)
CAUTION: The Graphics are used for the purpose of illustration only. Appearance of the computer may vary.
Connecting the USB cable
After you have completed connecting the DVI/VGA/DP cable, follow the procedure below to connect the USB cable to the computer and complete your monitor setup:
1. Connect the upstream USB port (cable supplied) to an appropriate USB port on your computer. (See bottom
view for details.)
2. Connect USB peripherals to the downstream USB ports (side or bottom) on the monitor. (See side
or bottom view for details.)
3. Plug the power cables for your computer and monitor into a nearby outlet.
4. Turn on the monitor and the computer.
If your monitor displays an image, installation is complete. If it does not display an image, see Solving Problems
.
5. Use the cable slot on the monitor stand to organize the cables.

Dell U2713HM Specifications

General

Screen Size	27 inches
Resolution	2560 x 1440
Panel Type	IPS
Aspect Ratio	16:9
Refresh Rate	60 Hz
Brightness	350 cd/m²
Display Colors	16.7 million
HDCP Support	Yes
Response Time	8 ms (gray to gray)
Contrast Ratio	1000:1
Viewing Angle	178°/178°
Color Gamut	99% sRGB
Ports	DisplayPort, HDMI, DVI-D, VGA, USB 3.0
Stand Adjustments	Height, Pivot, Swivel, Tilt
VESA Mount	100 mm x 100 mm
