3. Follow the steps to remove the SATA cable and the power cable:
a. Disconnect the SATA cable and power cable from the hard drive [1] [2].
b. Remove the screws that secure the hard-drive bracket [3] and lift it upwards to remove it from the
computer [4].
4. Follow the steps to remove the hard-drive bracket.
a. Remove the screws that secure the hard-drive bracket.
b. Lift and remove the hard drive from the hard-drive bracket.
Installing the Hard Drive
1. Replace the hard drive into the hard-drive bracket.
2. Install the screws that secure the hard-drive bracket.
3. Install the hard drive into its slot in the computer.
4. Install the screws that secure the hard drive to the computer.
5. Connect the SATA cable and the power cable to the hard drive.
11
