Removing and installing components
Recommended tools
The procedures in this document require the following tools:
• Phillips #0 screwdriver
• Phillips #1 screwdriver
• Plastic scribe
NOTE: The #0 screw driver is for screws 0-1 and the #1 screw driver is for screws 2-4
Screw size list
Table 2. Screw size list
Component
M2x3.5
M3X3
M3X5
M3X6
6-32X1/4"
WLAN 1
SSD card 1
Power supply unit (PSU) 3
IO module 2
Internal antenna 2
Card reader 2
HDD Caddy Stand-O 1
System board 1 5
Front IO bracket 1
3
Removing and installing components 15
