10. Replace the computer cover (see Replacing the Computer Cover).
11. Connect your computer and devices to electrical outlets, and turn them on.
I/O Panel
I/O-Panel Components
Removing the I/O Panel
1. Follow the procedures in Before You Begin.
2. Remove the computer cover (see Removing the Computer Cover).
3. If your computer includes a card retention mechanism to secure the x16 card, press the release tab downward gently and then pivot the mechanism
upward.
4. Unhook the floppy drive cable from clips on processor shroud and move it out of the way.
NOTICE: To connect a network cable, first plug the cable into the network port or device and then plug the cable into the computer.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.
diagnostic, hard drive activity,
and network lights
Integrated audio connector with
jumper block installed
To Next Page
