Installing the battery cable
1. Connect the battery cable to the battery cable on the battery.
2. Install the:
a. battery
b. back cover
3. Follow the procedure in After working inside your computer
Removing the solid state drive (SSD) bracket
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. back cover
b. battery
3. To remove the SSD :
a. Remove the screws that secure the SSD [1] .
b. Lift to remove the SSD from the computer [2].
16
