Installing the system board
1. Align the system board into its slot on the computer chassis.
2. Install the screws that secure the system board to the computer.
3. Connect the power supply and display cables to their connectors.
4. Connect the following cables:
a. Display power supply cable
b. Display connector cable
5. Install the:
a. display assembly
b. system fan
c. LED board
d. heat sink
e. memory
f. SSD
g. WLAN card
h. battery
i. back cover
6. Follow the procedure in After working inside your computer
36
