Delta AS332P-A User Manual

 AS100 Series
Model
Item
AS132T-A
AS132P-A
AS132R-A
AS148T-A
AS148P-A
AS148R-A
AS164T-A
AS164P-A
AS164R-A
Supply voltage
100 ~ 240VAC (-15% ~ 10%); 50 / 60Hz ± 5%
Max. inrush
current
140 A (@264VAC，I
2
t = 29.4 A
2
S)
Power fuse rating
2.5 A / 250 VAC
Power
consumption (W)
130 VA
MAX
Internal power
consumption (W)
2.64 3.84 3 4.8 3.36 5.76
Current output
(DC 24V)
500 mA
Output shortt-
circuit protection
(DC 24V)
Yes
Electronical
isolation
3,000 VAC (Primary-secondary); 3,000 VAC (Primary-FE); 500 VAC (Secondary-FE)
Insulation voltage
Above 5 MΩ
The voltage between all inputs/outputs and the ground is 500 VAC.
Ground
The diameter of the ground should not be less than the diameters of the
cables connected to the terminals L and N.
Weight (g)
550
600
650
700
750
800
Communication
port isolation
USB, COM1, COM2, and CAN ports: 500 VAC
Ethernet: 1500 VAC
 AS300 Series: Electrical specifications for the inputs on digital input/output module. The signals
passing through the inputs are 24 VDC signals.
Model
Item
AS332T-A
AS332P-A
AS320T-B
AS320P-B
AS324MT-A
Number of inputs
16 (X0.0-X0.15) 8 (X0.0-X0.7) 12 (X0.0-X0.11)
Terminal connector
type
MIL connector
Removable spring-type
terminal blocks
MIL connector
Input type
Digital input
Input form
Direct current (sinking or sourcing)
X0.0+–X0.3+/X0.0- to
X0.3-: differential input
X0.4–X0.11: Direct current
(sinking or sourcing)
Input voltage/
current
24 VDC
5 mA
X0.0+
–X0.3+/X0.0- to X0.3-:
5 VDC, 5 mA
X0.4–X0.11: 24 VDC, 5 mA
Action
level
OFF→ON
>15 VDC
X0.0+–X0.3+/X0.0- to X0.3-
:
>0.2VDC
X0.4–X0.11: >15VDC
ON→OFF
<5 VDC
X0.0+–X0.3+/X0.0- to
X0.3-: <-0.2VDC
X0.4–X0.11: <5VDC
Response
time
OFF→ON
X0.0~X0.11: < 2.5μs
X0.12~X0.15: < 50μs
X0.0+–X0.3+/X0.0- to
X0.3-： < 0.125 μs
X0.4–X0.11: < 2.5μs
