Delta CP2000 Series User Manual

Chapter 09 SpecificationsCP2000
9-2
9-1 230V Series
Frame A B C D E
Model: VFD_ _ _CP23_-_
_
007 015 022 037 055 075 110 150 185 220 300 370 450 550 750 900
*Out
p
ut Ratin
g
Li
g
ht Dut
y
Rated output
capacity [kVA]
2 3 4 6 8.4 12 18 24 30 36 42 58 72 86 110 128
Rated output
current [A]
5 7.5 10 15 21 31 46 61 75 90 105 146 180 215 276 322
Applicable motor
output [kW]
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
Applicable motor
output [HP]
1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 120
Overload tolerance 120% of rated current for 1 minute during every 5 minutes
Max. output
frequency [Hz]
599.00 400.00
Carrier frequency
[kHz]
2–15 (Default: 8) 2–10 (Default: 6)
2–9
(Default: 4 )
Normal Dut
y
Rated output
capacity [kVA]
1.2 2 3.2 4.4 6.8 10 13 20 26 30 36 48 58 72 86 102
Rated output
current [A]
3 5 8 11 17 25 33 49 65 75 90 120 146 180 215 255
Applicable motor
output [kW]
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 19 22 30 37 45 55 75
Applicable motor
output [HP]
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Overload tolerance
120% of rated current for 1 minute during every 5 minutes;
160% of rated current for 3 seconds during every 25 seconds
Max. output
frequency [Hz]
599.00 400.00
Carrier frequency
[kHz]
2–15 ( Default: 8) 2–10 (Default: 6)
2–9
(Default: 4)
In
p
ut Ratin
g
Input
current [A]
Light duty 6.4 9.6 15 22 25 35 50 65 83 100 116 146 180 215 276 322
Normal
duty
3.9 6.4 12 16 20 28 36 52 72 83 99 124 143 171 206 245
Rated voltage /
Frequency
3 phase, 200–240 V
AC
[-15%– +10%], 50/60 Hz
Operating voltage
range
170–264 V
AC
Frequency tolerance 47–63 Hz
Efficiency [%] 97.8 98.2
Power Factor >0.98
Weight [Kg] 2.6± 0.3 5.4± 1 9.8± 1.5 38.5± 1.5 64.8± 1.5
Cooling method
Natural
cooling
Fan cooling
Braking chopper Frame A, B, C: Built-in Frame D above: Optional
DC choke Frame A, B, C: Optional Frame D above: Built-in 3%
EMC Filter Optional
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter
9-7 Derating Curve of Ambient Temperature.
 Select the AC motor drive with capacity one grade larger for the impact load application.
 Refer to Chapter 9-6 Specification for Operation Temperature and Protection Level for the protection level of each model.
 *The default setting is Light Duty, you can select Normal Duty and Light Duty by setting Pr.00-16.
