Delta CP2000 Series User Manual

Chapter 09 SpecificationsCP2000
9-3
9-2 460V Series
Frame A B C D0
Model VFD_ _ _CP43_-_ _
Model VFD_ _ _CP4E_-_ _
007 015 022 037 040 055 075 110 150 185 220 300 370 450 550
*1
Out
p
ut ratin
g
Li
g
ht dut
y
Rated output
capacity [kVA]
2.4 3.3 4.4 6.8 8.4 10.4 14.3 19 25 30 36 48 58 73 88
Rated output current
[A]
3 4.2
*2
5.5
*2
8.5
*2
10.5 13
*2
18
*2
24
*2
32
*2
38
*2
45 60
*2
73
*2
91 110
Applicable motor
output [kW]
0.75 1.5 2.2 3.7 4 5.5 7.5 11 15 18.5 22 30 37 45 55
Applicable motor
output [HP]
1 2 3 5 5 7.5 10 15 20 25 30 40 50 60 75
Overload tolerance 120% of rated current for 1 minute during every 5 minutes
Max.output
frequency [Hz]
599.00
Carrier frequency
[kHz]
2–15 (Default: 8) 2–10 (Default: 6)
Normal dut
y
Rated output
capacity [kVA]
2.2 2.4 3.2 4.8 7.2 8.4 10.4 14.3 19 25 30 36 48 58 73
Rated output current
[A]
1.7 3.0 4.0 6.0 9.0 10.5 12 18 24 32 38 45 60 73 91
Applicable motor
output [kW]
0.4 0.75 1.5 2.2 3.7 4 5.5 7.5 11 15 18.5 22 30 37 45
Applicable motor
output [HP]
0.5 1 2 3 5 5 7.5 10 15 20 25 30 40 53 60
Overload tolerance
120% of rated current for 1 minute during every 5 minutes;
160% of rated current for 3 seconds during every 25 seconds
Max.output
frequency [Hz]
599.00
Carrier frequency
[kHz]
2–15 (Default: 8) 2–10 (Default: 6)
In
p
ut ratin
g
Input
current [A]
Light duty 4.3 6 8.1 12.4 16 20 22 26 35 42 50 66 80 91 110
Normal
duty
3.5 4.3 5.9 8.7 14 15.5 17 20 26 35 40 47 63 74 101
Rated voltage /
Frequency
3 phase, 380–480 V
AC
[-15%– +10%), 50/60 Hz
Operating voltage range 323–528 V
A
C
Frequency tolerance 47–63 Hz
Efficiency [%] 97.8
Power factor >0.98
Weight [Kg] 2.6± 0.3 5.4± 1 9.8± 1.5 27± 1
Cooling method
Natural
cooling
Fan cooling
Braking chopper
Frame A, B, C: Built-in;
Frame D0 above: Optional
DC choke
Frame A, B, C: Optional;
Frame D0 above: Built-in 3%
EMC Filter
Frame A, B, C of VFD_ _ _ _CP4EA-_ _: Built-in;
Frame A, B, C of VFD_ _ _ _CP43A-_ _: no built-in;
Frame D0 above: Optional
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter
9-7 Derating Curve of Ambient Temperature.
 Select the AC motor drive with capacity one grade larger for the impact load application.
 Refer to Chapter 9-6 Specification for Operation Temperature and Protection Level for the protection level of each model.
 *
1
The default setting is Light Duty, you can select Normal Duty and Light Duty by setting Pr.00-16.
 *
2
It means the rated output current is for the models of Version B. (e.g. VFD015CP43B-21)
