Table 5-5: Definition of RS485
PIN FUNCTION
1 VCC
2 GND
3 DATA+
4 DATA-
5 DATA+
6 DATA-
Figure 5-6: Multi-inverter connection illustration
Table 5-6: RS-485 data format
RS-485 Data format
Baud rate 9600 / 19200
Data bit 8
Stop bit 1
Parity N/A
