Delta RPI M6A Quick Installation Guide

24
Quick installation guide for solar inverters RPI M6A M8A M10A EU V4 EN 5013221703 00 2017-11-16
External power-off (EPO)
E-Today: 0kWh
Power: 0W
Status: On Grid
12.Jun 2016 15:32
1. If the default information is displayed, press the
ESC
button to open the main menu.
Otherwise, press the
ESC
button repeatedly until the main menu is displayed.
Inverter Info.
General Settings
Install Settings
Active/Reactive Pwr
FRT
2. Use the and buttons to select the Install Settings entry and then press
the
ENT
button.
Password: * * * *
energy production
Adj. would effect
Warning:
3. This function is protected with password 5555.
Use the
and buttons to set the individual numerals.
Press the
ENT
button to conrm a numeral.
Grid Settings
DC Injection
Dry Contact
RCMU: ON
EPO: Normal Close
4. Use the buttons and to select the entry EPO and press the
ENT
button.
5. Use the and buttons to select an option and then press the
ENT
button.
Available options
Nrm. open (normally open): The relay operates as a normally open device.
Nrm. closed (normally closed): The relay operates as a normally closed device.
Active power limitation
Change this setting only after consultation with
Delta customer service.
To change this setting, you need a special
password that you receive from Delta customer
service. You can nd the contact information on
the back of this document.
E-Today: 0kWh
Power: 0W
Status: On Grid
12.Jun 2016 15:32
1. If the default information is displayed, press the
ESC
button to open the main menu.
Otherwise, press the
ESC
button repeatedly until the main menu is displayed.
Inverter Info.
General Settings
Install Settings
Active/Reactive Pwr
FRT
2. Use the and buttons to select the Install Settings entry and then press
the
ENT
button.
Password: * * * *
energy production
Adj. would effect
Warning:
3. Enter the password provided by Delta customer service.
Use the
and buttons to set the individual numerals.
Press the
ENT
button to conrm a numeral.
AC Connection: 3P3W
EPO: Normal Close
Anti-islanding: ON
Max. Power: 10000W
Return to Factory
4. Use the and buttons to select the Max. Power entry and then press the
ENT
button.
5. Use the and buttons to congure a value and then press the
ENT
button.
Commissioning – further settings (optional)
