Delta RPI M6A Quick Installation Guide

25
Quick installation guide for solar inverters RPI M6A M8A M10A EU V4 EN 5013221703 00 2017-11-16
Dry contacts
E-Today: 0kWh
Power: 0W
Status: On Grid
12.Jun 2016 15:32
1. If the default information is displayed, press the
ESC
button to open the main menu.
Otherwise, press the
ESC
button repeatedly until the main menu is displayed.
Inverter Info.
General Settings
Install Settings
Active/Reactive Pwr
FRT
2. Use the and buttons to select the Install Settings entry and then press
the
ENT
button.
Password: * * * *
energy production
Adj. would effect
Warning:
3. This function is protected with password 5555.
Use the
and buttons to set the individual numerals.
Press the
ENT
button to conrm a numeral.
Grid Settings
DC Injection
Dry Cont. Disable
RCMU: ON
EPO: Normal Close
4. Use the buttons and to select the Dry Cont. entry and press the
ENT
button.
On Grid
Fan Fail
Insulation
Disable
5. Use the and buttons to select an option and then press the
ENT
button.
See “Connecting the digital inputs, dry contacts and external power-off (optional)”,
page 20 for the available options.
Commissioning – further settings (optional)
