Delta RPI M6A Quick Installation Guide

26
Quick installation guide for solar inverters RPI M6A M8A M10A EU V4 EN 5013221703 00 2017-11-16
Input (DC) RPI M6A RPI M8A RPI M10A
Recommended maximum PV power
1)
7500 W
P
10000 W
P
12500 W
P
Maximum output 6600 W 8800 W 11000 W
Input voltage range 200 ... 1000 V
DC
Maximum input voltage 1000 V
DC
Nominal voltage 600 V
DC
Cut-in voltage >250 V
DC
Cut-in power 40 W
MPP operating voltage range 200 ... 1000 V
DC
MPP operating voltage range at full power
Symmetrical load 315 ... 800 V
DC
415 ... 800 V
DC
415 ... 800 V
DC
Asymmetrical load (60/40 %) 425 ... 800 V
DC
565 ... 800 V
DC
415 ... 800 V
DC
Maximum input power, total (DC1/DC2) 20 A (10 A / 10 A) 20 A (10 A / 10 A) 25 A (15 A / 10 A)
Maximum short circuit power upon fault 13 A / 13 A 13 A / 13 A 19.5 A / 13 A
Number of MPP trackers Parallel inputs: 1 MPP tracker, separate inputs: 2 MPP tracker
Maximum asymmetry 60%/40%
Number of DC inputs, total (DC1/DC2) 2 (1/1) 2 (1/1) 3 (2/1)
Electrical isolation No
Overvoltage category
2)
II
Output (AC) RPI M6A RPI M8A RPI M10A
Maximum apparent power
3)
6300 VA 8400 VA 10500 VA
Rated apparent power 6000 VA
4)
8000 VA 10000 VA
Voltage range
5)
230 ± 20% /400 V
AC
± 20%, 3 phases + protective ground conductor(PE) or
3 phases + N + protective ground conductor (PE)
Nominal current 8.7 A 11.6 A 14.5 A
Maximum current 9.7 A 13 A 16 A
Switch-on current 31 A / 100 µs
Nominal frequency 50 / 60 Hz
Frequency range
5)
50 ± 5 Hz / 60 ± 5 Hz
Power factor conguration area 0.8 cap ... 0.8 ind
Total harmonic distortion (THD) < 3% at rated apparent power
DC injection < 0.5% at rated current
Power loss in night mode < 2 W
Overvoltage category
2)
III
Technical data

Delta RPI M6A Specifications
