Delta RPI M6A Installation Guide

23
Installation guide for solar inverters RPI M6A M8A M10A EU V5 EN 2022-08-15
Commissioning – further settings (optional)
Baud rate for RS485
E-Today: 0kWh
Power: 0W
Status: On Grid
12.Sep 2019 15:32
1. If the default information is displayed, press the
ESC
button to open the main
menu. Otherwise, press the
ESC
button repeatedly until the main menu is
displayed.
Inverter Info.
General Settings
Install Settings
Active/Reactive Pwr
FRT
2. Use the and buttons to select the General Settings entry and then
press the
ENT
button.
Baud rate
Date & Time
Language
3. Use the buttons and to select the entry Baud rate and press the
ENT
button.
38400
19200
9600
4. Use the and buttons to select a value and then press the
ENT
button.
AC connection type
By default, the AC connection type is set to 3P4W (3 phases + N + PE). You only need to change this
setting if you are using an AC system with 3 phases + PE (3P3W).
E-Today: 0kWh
Power: 0W
Status: On Grid
12.Sep 2019 15:32
1. If the default information is displayed, press the
ESC
button to open the main
menu. Otherwise, press the
ESC
button repeatedly until the main menu is
displayed.
Inverter Info.
General Settings
Install Settings
Active/Reactive Pwr
FRT
2. Use the and buttons to select the Install Settings entry and then
press the
ENT
button.
Password: * * * *
energy production
Adj. would effect
Warning:
3. This function is protected with password 5555.
Use the and buttons to set the individual numerals.
Press the
ENT
button to conrm a numeral.
AC Connection: 3P4W
EPO: Normal Close
Anti-islanding: ON
Max. Power: 10000W
Return to Factory
4. Use the buttons and to select the entry AC Connection and press
the
ENT
button.
AC Connection: 3P3W
EPO: Normal Close
Anti-islanding: ON
Max. Power: 10000W
Return to Factory
5. Use the and buttons to select the 3P3W entry and then press the
ENT
button.
