Delta RPI M6A Installation Guide

6
Installation guide for solar inverters RPI M6A M8A M10A EU V5 EN 2022-08-15
1
2
4 3
1 Display, buttons, and LEDs 3 Mounting hole and grounding connection
2 Type plate 4 Mounting hole
75 86 9
75 86 9
M6A and M8A electrical connections
M10A electrical connections
Components of the Inverter
5 AC/DC disconnector 7 RS485 connection 9 Communication connection
6 DC inputs 8 AC connection

Delta RPI M6A Specifications

General

Brand	Delta
Model	RPI M6A
Category	Inverter
Language	English
