Delta S Series - System Overview and Operation; S-Series System Overview

Delta Electric Servo Press - S Series
Installation and Maintenance Instructions
5
2. Comprehensive System Structure
2.1 S-Series
The following figure uses the AM-ESP-S010-XXXX as an example:
RS-485 or RJ-45 connector
(This item is to be prepared
by the customer)
Front view
Safety light curtain
(This item is to be prepared or
purchased optionally by the
customer)
Side view
Please use a Windows operating system for
personal computers
(This item is to be prepared by the customer)
