52
6
Summary of Parameter Settings
This chapter summarizes all the 10 groups of parameters. The page number shown in
parenthesis will direct you to the explanation of settings associated with each parameter.
NO. Parameter Name Function Explanation Parameter Value
Factory
Setting
00
Command frequency
source select
Command frequency
source select
d0000: Command frequency input determined
by the digital control panel
d0000
(page 20)
d0001: Command frequency input determined
by the analog signal (DC 0 to +10 V) +
(DC 4 to 20 mA)
d0002: Command frequency input determined
by remote control via the RS-485 serial
interface
01
Operation
Command source
Operation command
source select
d0000: Operating instructions determined by
the digital control panel
d0000
(page 21)
d0001: Operating instructions determined by
the external terminal connections,
keypad STOP key effective
d0002: Operating instructions determined by
the external terminal connections,
keypad STOP key not effective
d0003 Operating instructions determined by
the RS-485 serial interface, keypad
STOP key effective
d0004: Operating instructions determined by
the RS-485 serial interface, keypad
STOP key not effective
02 Motor sto
method Motor sto
method d0000: RAMP stop d0000
(page 20)
d0001:
Coasting to stop
03 V / F curve setting Max. o
eratin
d050.0 - d400.0 Hz d060.0
04 (page 21) Max. voltage frequency d010.0 - d400.0 Hz d060.0
05 Max. output voltage d002.0 - d255.0 V d220.0
06 Mid-point frequency d000.1 - d400.0 Hz d001.5
07 Mid-point voltage d002.0 - d255.0 V d010.0
08 Min. output frequency d000.1 - d020.0 Hz d001.5
09 Min. output voltage d002.0 - d050.0 V d010.0
