Electrical Characteristics
MODEL NO.
Input Voltage
(V)
Phase
3 Phase Motor
Rating
(KW)(HP)
Output
Power
(KVA)
Input
Current
(A)
Output
Current
(A)
200-240 1 Phase 0.75 (1) 1.9 11.9 5
VFD007B21A
200-240 3 Phase 0.75 (1) 1.9 7.0 5
VFD007B23A 200-240 3 Phase 0.75 (1) 1.9 5.7 5
VFD007B43A 380-480 3 Phase 0.75 (1) 2.3 3.2 2.7
200-240 1 Phase 1.5 (2) 2.5 15.3 7
VFD015B21A
200-240 3 Phase 1.5 (2) 2.5 9.4 7
VFD015B23A 200-240 3 Phase 1.5 (2) 2.5 7.6 7
VFD015B43A 380-480 3 Phase 1.5 (2) 3.2 4.3 4.2
200-240 1 Phase 2.2 (3) 4.2 22 11
VFD022B21A
200-240 3 Phase 2.2 (3) 4.2 14 11
VFD022B23B 200-240 3 Phase 2.2 (3) 4.2 15.5 11
VFD022B43B 380-480 3 Phase 2.2 (3) 4.2 5.9 5.5
VFD037B23A 200-240 3 Phase 3.7 (5) 6.5 20.6 17
VFD037B43A 380-480 3 Phase 3.7 (5) 6.5 11.2 8.5
VFD055B23A 200-240 3 Phase 5.5 (7.5) 9.5 26 25
VFD055B43A 380-480 3 Phase 5.5 (7.5) 9.9 14 13
VFD075B23A 200-240 3 Phase 7.5 (10) 12.5 34 33
VFD075B43A 380-480 3 Phase 7.5 (10) 13.7 19 18
VFD110B23A 200-240 3 Phase 11 (15) 18.3 50 49
VFD110B43A 380-480 3 Phase 11 (15) 18.3 25 24
VFD150B23A 200-240 3 Phase 15 (20) 24.7 60 65
VFD150B43A 380-480 3 Phase 15 (20) 24.4 32 32
VFD185B23A 200-240 3 Phase 18.5 (25) 28.6 75 75
VFD185B43A 380-480 3 Phase 18.5 (25) 28.9 39 38
VFD220B23A 200-240 3 Phase 22 (30) 34.3 90 90
VFD220B43A 380-480 3 Phase 22 (30) 34.3 49 45
VFD300B23A 200-240 3 Phase 30 (40) 45.7 110 120
VFD300B43A 380-480 3 Phase 30 (40) 45.7 60 60
VFD370B23A 200-240 3 Phase 37 (50) 55.0 142 145
VFD370B43A 380-480 3 Phase 37 (50) 55.6 63 73
VFD450B43A 380-480 3 Phase 45 (60) 69.3 90 91
VFD550B43A 380-480 3 Phase 55 (75) 84 130 110
VFD750B43A 380-480 3 Phase 75 (100) 114 160 150
Input Frequency: 47-63 Hz
Output Voltage: Proportional to input voltage
Output Frequency: 0.1 too 400Hz
Max. Ambient Temp: 40 degree C (*)
Enclosure: ENCLOSED Type 1
*: Max. Ambient Temp is 50 degree C for 7.5-15hp.
