5
VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
5-1
CHAPTER 5 DESCRIPTION OF PARAMETER SETTINGS
Group 0: User Parameters a: This parameter can be set during operation.
00 - 00
Identity Code of AC Drive Factory setting: ##
Factory Setting
00 - 01
Rated Current Display of the AC drive Factory setting: #.#
Settings None Unit: 0.1 A
This parameter displays the rated current of the AC drive. It is based on Pr.00-00, and is
read-only.
Users can use the following table to check if the rated current of the AC drive is
corresponds to the identity code.
230V Series
KW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
HP 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50
Pr.00-00 04 06 08 10 12 14 16 18 20 22 24 26
Rated
current (A)
5.0 7.0 11 17 25 33 49 65 75 90 120 146
Max.
Carried
Freq.
15KHz 15 KHz 9 KHz
460V Series
KW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
HP 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50 60 75 100
Pr.00-00 05 07 09 11 13 15 17 19 21 23 25 27 29 31 33
Rated
Current (A)
2.7 4.2 5.5 8.5 13 18 24 32 38 45 60 73 91 110 150
Max.
Carried
Freq.
15 KHz 15 KHz 9 KHz 6 KHz
00 - 02
Parameter Reset Factory Setting: 00
Settings 08 Keypad Lock
10 All parameters are reset to factory settings
This setting allows the user to return all parameters to the factory default settings except
the fault records (Pr.06-08 ~ Pr06-11).
If this parameter is set to 08, the operation function of VFD-PU01 keypad is disabled. At
this time, you should set Pr.00-02 to 00 to disable parameter lock function.
