7-3 Fuse Specification Chart
Fuse specifications lower than the table below are allowed.
For installation in the United States, branch circuit protection must be provided in accordance with the
National Electrical Code (NEC) and any applicable local codes. Use UL classified fuses to fulfill this
requirement.
For installation in Canada, branch circuit protection must be provided in accordance with Canadian
Electrical Code and any applicable provincial codes. Use UL classified fuses to fulfill this requirement.
230V Model
Input Current I [A] Line Fuse
Normal Duty Light Duty I [A] Bussmann P/N
VFD007CP23A-21 3.9 6.4 15 JJN-15
VFD015CP23A-21 6.4 9.6 20 JJN-20
VFD022CP23A-21 12 15 30 JJN-30
VFD037CP23A-21 16 22 40 JJN-40
VFD055CP23A-21 20 25 50 JJN-50
VFD075CP23A-21 28 35 60 JJN-60
VFD110CP23A-21 36 50 100 JJN-100
VFD150CP23A-21 52 65 125 JJN-125
VFD185CP23A-21 72 83 150 JJN-150
VFD220CP23A-21 83 100 200 JJN-200
VFD300CP23A-21 99 116 225 JJN-225
VFD370CP23A-00/23A-21 124 146 250 JJN-250
VFD450CP23A-00/23A-21 143 180 300 JJN-300
VFD550CP23A-00/23A-21 171 215 400 JJN-400
VFD750CP23A-00/23A-21 206 276 450 JJN-450
VFD900CP23A-00/23A-21 245 322 600 JJN-600
460V Model
Input Current I [A] Line Fuse
Normal Duty Light Duty I [A] Bussmann P/N
VFD007CP43A-21/4EA-21 3.5 4.3 10 JJS-10
VFD015CP43B-21/4EB-21 4.3 6.0 10 JJS-10
VFD022CP43B-21/4EB-21 5.9 8.1 15 JJS-15
VFD040CP43A-21/4EA-21 8.7 12.4 25 JJS-20
VFD037CP43B-21/4EB-21 14 16 30 JJS-20
VFD055CP43B-21/4EB-21 15.5 20 40 JJS-30
VFD075CP43B-21/4EB-21 17 22 40 JJS-40
VFD110CP43B-21/4EB-21 20 26 50 JJS-50
VFD150CP43B-21/4EB-21 26 35 60 JJS-60
VFD185CP43B-21/4EB-21 35 42 75 JJS-75
VFD220CP43A-21/4EA-21 40 50 100 JJS-100
VFD300CP43B-21/4EB-21 47 66 125 JJS-125
VFD370CP43B-21/4EB-21 63 80 150 JJS-150
VFD450CP43S-00/43S-21 74 91 175 JJS-175
VFD550CP43S-00/43S-21 101 110 250 JJS-250
VFD750CP43B-00/43B-21 114 150 300 JJS-300
VFD900CP43A-00/43-21 157 180 300 JJS-300
VFD1100CP43A-00/43A-21 167 220 400 JJS-400
VFD1320CP43B-00/43B-21 207 260 500 JJS-500
VFD1600CP43A-00/43A-21 240 310 600 JJS-600
VFD1850CP43B-00/43B-21 300 370 600 JJS-600
VFD2200CP43A-00/43A-21 380 460 800 JJS-800
VFD2800CP43A-00/43A-21 400 530 1000 KTU-1000
VFD3150CP43A-00/43C-00/43C-21 494 616 1200 KTU-1200
VFD3550CP43A-00/43C-00/43C-21 555 683 1350 KTU-1350
VFD4000CP43A-00/43C-00/43C-21 625 770 1500 KTU-1500
VFD5000CP43A-00/43C-00/43C-21 * 866 930 1600 170M6019
VFD5600CP43A-00/43C-21 930 1094 2000 170M6021
VFD6300CP43A-00/43C-21 1094 1212 2000 170C6021
*VFD5000CP43A-00/43C-00/43C-21 models do not have UL certification.
Table 7-15
