Chapter 12 Description of Parameter SettingsME300
12.1-05-5
Accumulated Watt-hour for a Motor (W-hour)
Accumulated Watt-hour for a Motor in Low Word (kW-hour)
Accumulated Watt-hour for a Motor in High Word (MW-hour)
Default: 0.0
Settings Read only
Pr.05-26–05-30 records the amount of power the motors consume. The accumulation begins
when the drive is activated and the record is saved when the drive stops or turns OFF. The
amount of consumed watts continues to accumulate when the drive is activated again. To clear
the accumulation, set Pr.00-02 as 5 to return the accumulation record to 0.
The accumulated total kilowatts of the motor per hour = Pr.05-30 x 1000000 + Pr.05-29 x 1000 +
Pr.05-28 Wh
Example: when Pr.05-30 = 76 MWh and Pr.05-29 = 150 kWh, Pr.05-28 = 400 Wh (or 0.4 kWh),
the accumulated total kilowatts of the motor per hour = 76 x 1000000 + 150 x 1000 + 40 =
76150400 Wh = 76150.4 kWh
Accumulated Motor Operation Time (Min.)
Default: 0
Settings 0–1439
Accumulated Motor Operation Time (Day)
Default: 0
Settings 0–65535
Use Pr.05-31 and Pr.05-32 to record the motor operation time. To clear the operation time, set
Pr.05-31 and Pr.05-32 as 00. An operation time shorter than 60 seconds is not recorded.
Induction Motor (IM) or Permanent Magnet Synchronous Motor Selection
Default: 0
Settings 0: Induction Motor
1: SPM
2: IPM
Full-load Current for a Permanent Magnet Synchronous Motor
Default: #.#
Settings 0–120% of the drive’s rated current
Rated Power for a Permanent Magnet Synchronous Motor
Default: #.##
Settings 0.00–655.35 kW
Sets the rated power for the permanent magnet synchronous motor. The default is the drive’s
power value.
