When Pr.13-00 is not 0, the corresponding parameters appear in the APP page according to the
setting for Pr.13-00. In each selected application, you can view the parameters by pressing the digital
dial button. If Pr.13-00 = 1 and you do not set any parameters in Pr.13-01–Pr.13-50, you cannot enter
the sub-layer of the USER page. The parameter settings in the APP page are the same as those in
other parameter groups: rotate and then press the digital dial to select and set the parameter’s value.
Follow the process below to set the user-defined application selection (Pr.13-00 = 1).
1. Activate the application selection by setting Pr.13-00.
2. After setting Pr.13-00 = 1, you can enter the definitions for Pr.13-01–50.
3. The default setting for Pr.13-01–50 is P 0.00. Press the digital dial to set the corresponding
parameters for Pr.13-01–50 in sequence.
4. Setting the corresponding parameters for Pr.13-01–50 is the same as those in other parameter
groups: rotate and press the digital dial to select and set the parameter’s value.
Note 1: you cannot set values for read-only parameters.
Note 2: you must set Pr.13-01, 02…50 in sequence, or the display shows “Err”.
5. To change the corresponding parameters, go back to Pr.13-01–13-50 to modify.
6. After setting, to remove a set parameter, set from the last parameter (set to 0.00) first, or the
display shows “Err”.
For example, if there are 5 user-defined parameters (Pr.13-01, 13-02…13-05), to remove Pr.13-
02, you must remove Pr.13-05 first, then 13-04, then 13-03, and then 13-02.
7. When you finish setting, press MODE to go back to the APP page, and then press the digital
dial again. The keypad displays “USER”. After you press the digital dial again, the corresponding
parameter that you set appears.
Follow the process below to set specific application selection (Pr.13-00 = 2, 3, 4, 5, or 7).
Set Pr.13-00 = 1
Activates user-defined
application selection.
Set Pr.13-01–13-50
user-defined parameters in
order.
When finishing setting values,
press MODE button to display
the APP page, and then press
digital dial to display the
USER page. Press digital dial
again to display the user-
defined parameters.
Use digital dial to select
defined parameters, and
press ENTER to check the
setting.
To remove a user-defined
parameter, go back to
parameter group 13, and set
the parameter as 0.00 from
the last defined parameter in
order.
To remove a user-defined
parameter, go back to
parameter group 13, and set
the parameter as 0.00 from
the last defined parameter in
order.
Set Pr.13-00 = 3, 4, 5 or 7
(3, 4, 5 and 7 represent
different industries).
After selecting, press
MODE to go back to the
APP page. Then press
digital dial to display the
industry abbreviation. Press
digital dial again to set the
application parameters.
Rotate the digital dial to
select the defined
parameters, and then
press it to check the
setting.
