Delta VFD2A7ME43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsME300
11-19
05 Motor Parameters
Pr. Explanation Settings Default
05-00
Motor parameter
auto-tuning
0: No function
1: Dynamic test for induction motor (IM)
2: Static test for induction motor (IM)
13: High frequency stall test for PM synchronous motor
0
05-01
Full-load current for
induction motor 1 (A)
10–120% of the drive’s rated current #.##

05-02
Rated power for induction
motor 1 (kW)
0.00–655.35 kW #.##

05-03
Rated speed for induction
motor 1 (rpm)
0–65535 rpm
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
1710
05-04
Number of poles for
induction motor 1
2–20 4
05-05
No-load current for
induction motor 1 (A)
0.00–Pr.05-01 default
#.##
05-06
Stator resistance (Rs) for
induction motor 1
0.000–65.535 Ω
#.###
05-07
Rotor resistance (Rr) for
induction motor 1
0.000–65.535 Ω
#.###
05-08
Magnetizing inductance
(Lm) for induction motor 1
0.0–6553.5 mH
#.#
05-09
Stator inductance (Lx) for
induction motor 1
0.0–6553.5 mH
#.#
05-13
Full-load current for
induction motor 2 (A)
10–120% of the drive’s rated current
#.##

05-14
Rated power for induction
motor 2 (kW)
0.00–655.35 kW
#.##

05-15
Rated speed for induction
motor 2 (rpm)
0–65535 rpm
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
1710
05-16
Number of poles for
induction motor 2
2–20 4
05-17
No-load current for
induction motor 2 (A)
0.00–Pr.05-13 default
#.##
05-18
Stator resistance (Rs) for
induction motor 2
0.000–65.535 Ω
#.###
05-19
Rotor resistance (Rr) for
induction motor 2
0.000–65.535 Ω
#.###
05-20
Magnetizing inductance
(Lm) for induction motor 2
0.0–6553.5 mH
#.#
