Delta VFD4A8ME21ANSAA User Manual

Chapter 11 Summary of Parameter SettingsME300
11-11
Pr. Explanation Settings Default
18: Forced to stop (Pr.07-20)
19: Digital up command
20: Digital down command
21: PID function disabled
22: Clear the counter
23: Input the counter value (MI6)
24: FWD JOG command
25: REV JOG command
28: Emergency stop (EF1)
29: Signal confirmation for Y-connection
30: Signal confirmation for Δ-connection
38: Disable write EEPROM function
40: Force coasting to stop
41: HAND switch
42: AUTO switch
49: Enable Drive
50: Master dEb input
56: Local/Remote selection
69: Auto-activate preheating function
71: Disable PID function, force PID output return to 0
72: Disable PID function, retain the output value
before disabled
73: Force PID integral gain return to 0, disable integral
74: Reverse PID feedback
83: Multi-motors (IM) selection bit 0
94: Programmable AUTO RUN
95: Pausing AUTO RUN
97: Multi-pumps switch by Hand / Auto mode
98: Simple positioning stop by forward limit
99: Simple positioning stop by reverse limit

02-09 UP / DOWN key mode
0: UP/DOWN by acceleration / deceleration time
1: UP/DOWN constant speed (Pr.02-10)
2: Pulse command (Pr.02-10)
3: External terminals UP/DOWN mode
0

02-10
Constant speed;
acceleration / deceleration
speed of UP/DOWN key
0.001–1.000 Hz/ms 0.001

02-11
Multi-function input
response time
0.000–30.000 sec. 0.005
