Delta VFD4A8ME21ANSAA User Manual

Chapter 3 InstallationME300
3-2
Frame
Air flow rate for cooling Power Dissipation
Model No.
Flow Rate
(Unit: cfm)
Flow Rate
(Unit: m
3
/hr)
Loss External
(Heat sink, unit: W)
Internal
(Unit: W)
Total
(Unit: W)
A
VFD2A5ME11ANNAA
VFD2A5ME11ANSAA
0 0
14.2 13.1 27.3
VFD2A8ME21ANNAA
VFD2A8ME21ANSAA
16.3 14.5 30.8
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
31 13.2 44.2
VFD1A5ME43ANNAA
VFD1A5ME43ANSAA
17.6 11.1 28.7
VFD2A7ME43ANNAA
VFD2A7ME43ANSAA
30.5 17.8 48.3
VFD0A8ME11ANNAA
VFD0A8ME11ANSAA
5.1 6.8 11.9
VFD1A6ME11ANNAA
VFD1A6ME11ANSAA
8 10 18
VFD0A8ME21ANNAA
VFD0A8ME21ANSAA
5.1 6.8 11.9
VFD1A6ME21ANNAA
VFD1A6ME21ANSAA
8 10.3 18.3
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
5.1 6.8 11.9
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
8.6 10 18.6
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
16.5 12.6 29.1
B
VFD0A8ME21AFNAA
VFD0A8ME21AFSAA
0 0
5.1 6.8 11.9
VFD1A6ME21AFNAA
VFD1A6ME21AFSAA
8 10.3 18.3
VFD2A8ME21AFNAA
VFD2A8ME21AFSAA
10 16.99
16.3 14.5 30.8
VFD4A8ME21AFNAA
VFD4A8ME21AFSAA
29.1 20.1 49.2
VFD4A8ME21ANNAA
VFD4A8ME21ANSAA
0 0 29.1 20.1 49.2
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
10 16.99
50.1 24.2 74.3
VFD4A2ME43ANNAA
VFD4A2ME43AFNAA
VFD4A2ME43ANSAA
VFD4A2ME43AFSAA
45.9 21.7 67.6
VFD1A5ME43AFNAA
VFD1A5ME43AFSAA
17.6 11.1 28.7
VFD2A7ME43AFNAA
VFD2A7ME43AFSAA
30.5 17.8 48.3
C
VFD4A8ME11ANNAA
VFD4A8ME11ANSAA
16 27.2
29.1 23.9 53
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
46.5 31 77.5
