Denon AVR-1610 Service Manual

119
AVR-1910/1620/1610/790/590
PARTS LIST OF EXPLODED VIEW (1910/790 model)
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : (Black model SP : (Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
50 nsp PCB MAIN ASSY 1910BKE3 7025HK0817010 *
50 nsp PCB MAIN ASSY 1910BKE2
7025HK0817060 *
50 nsp PCB MAIN ASSY 1910SPE2
7025HK0817050 *
50 nsp PCB MAIN ASSY 1910SPE1C
7025HK0817020 *
50 nsp PCB MAIN ASSY 790BKE3
7025HK0817070 *
50 nsp PCB MAIN ASSY 790BKEA
7025HK0817040 *
11A nsp PCB FRONT ASSY 1910BKE3
7025HK0817011 *
11A nsp PCB FRONT ASSY 1910BKE2
7025HK0817061 *
11A nsp PCB FRONT ASSY 1910SPE2
7025HK0817051 *
11A nsp PCB FRONT ASSY 1910SPE1C
7025HK0817021 *
11A nsp PCB FRONT ASSY 790BKE3
7025HK0817071 *
11A nsp PCB FRONT ASSY 790BKEA
7025HK0817041 *
z 9 - PCB P/S *
10 - PCB FUNC *
11 - PCB FRONT *
13 - PCB ENCODER *
14 - PCB H/P *
21 - PCB V.AUX *
22 - PCB MIC *
27 - PCB CNT *
29 - PCB CABLE GUIDE *
61 - PCB ENCODER CNT *
63 - PCB 19SPK *
78 - PCB SW *
79 - PCB SW CNT *
51 nsp PCB INPUT ASSY 1910BKE3
7025HK0817012 *
51 nsp PCB INPUT ASSY 1910BKE2
7025HK0817062 *
51 nsp PCB INPUT ASSY 1910SPE2
7025HK0817052 *
51 nsp PCB INPUT ASSY 1910SPE1C
7025HK0817022 *
51 nsp PCB INPUT ASSY 790BKE3
7025HK0817072 *
51 nsp PCB INPUT ASSY 790BKEA
7025HK0817042 *
57A nsp PCB POWER ASSY 1910BKE3
7025HK0817013 *
57A nsp PCB POWER ASSY 1910BKE2
7025HK0817063 *
57A nsp PCB POWER ASSY 1910SPE2
7025HK0817053 *
57A nsp PCB POWER ASSY 1910SPE1C
7025HK0817023 *
57A nsp PCB POWER ASSY 790BKE3
7025HK0817073 *
57A nsp PCB POWER ASSY 790BKEA
7025HK0817043 *
z 57 - PCB POWER *
56 - PCB SUPPLY *
26 - PCB 19GUIDE_L *
z 62 - PCB OUTLET *
71 - PCB CNT1 *
55 963189003440D PCB 19HDMI ASSY E3
7025HK0817015 *
55 963189004020D PCB 19HDMI ASSY E2, E1C, EA
7025HK0817055 *
33 nsp PCB 7CHAMP ASSY 1910BKE3
7025HK0817016 *
33 nsp PCB 7CHAMP ASSY 1910BKE2
7025HK0817066 *
33 nsp PCB 7CHAMP ASSY 1910SPE2
7025HK0817056 *
33 nsp PCB 7CHAMP ASSY 1910SPE1C
7025HK0817026 *
33 nsp PCB 7CHAMP ASSY 790BKE3
7025HK0817076 *
33 nsp PCB 7CHAMP ASSY 790BKEA
7025HK0817046 *
