Denon AVR-1610 Service Manual

77
AVR-1910/1620/1610/790/590
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
PCB MAIN ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1000 00D2630553006 IC NJM7805FA
J126780500130S
IC1002 00D2630554005 IC NJM7905FA J126790500020S
IC1003 963239003420S IC NJM2388F05 J126238800050S
IC1004 963239003480S IC NJM2388F33 J126238800330S
IC1005 963249004210D IC M30626FJPFP -
IC1006 00D2630553006 IC NJM7805FA J126780500130S
IC1007 00D9630326906 IC LC72722PM-TLM-E E2 J124727220010S
IC1008 00D2631274012 IC NJM2396F09 J126239600090S
Q1000,1001 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q1002 00D9600196302 TR KTA1268BL J5001268B0050S
Q1004 00D9600196302 TR KTA1268BL J5001268B0050S
Q1005 00D9600196700 TR KTC3200BL J5023200B0050S
Q1006 00D9630121509 TR KTC3875S J522038750210S
Q1007 00D9630219602 TR KRC106M J6020106M0010S
Q1008 00D9600196700 TR KTC3200BL J5023200B0050S
Q1009 00D9600196302 TR KTA1268BL J5001268B0050S
Q1010,1011 00D9600196700 TR KTC3200BL J5023200B0050S
Q1012 00D9630121208 TR KRC107M J6020107M0010S
Q1013-1015 00D9630121606 TR KRC107S J522107S00210S
Q1016 00D9600196302 TR KTA1268BL J5001268B0050S
Q1017,1018 00D9600196700 TR KTC3200BL J5023200B0050S
Q1019 00D9600196302 TR KTA1268BL J5001268B0050S
Q1020 00D9600196700 TR KTC3200BL J5023200B0050S
Q1031 00D9630121509 TR KTC3875S J522038750210S
Q1032 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
Q1033 00D9630044301 TR KTC2875B(MB) 1610, 1620, 590 J5222875B0010S
Q1034 00D9630255802 TR KTC3199Y J5023199Y0010S
Q1035 00D9630044301 TR KTC2875B(MB) 1610, 1620, 590 J5222875B0010S
Q1036 00D9630327808 TR KTA1281Y J5001281Y0010S
Q1037 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
Q1038 00D9600097304 TR KRC102M J6020102M0010S
Q1039 00D9630120704 TR KRA102S J520010200210S
Q1040 00D9600097304 TR KRC102M J6020102M0010S
Q1041,1042 00D9630121509 TR KTC3875S J522038750210S
Q1043 00D9630148508 TRKTA1504S J520015040150S
Q1044 00D9630120801 TR KRC102S J522010200210S
Q1045 00D9630120704 TR KRA102S J520010200210S
Q1046-1049 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q1050,1051 00D9630044301 TR KTC2875B(MB) 1610, 1620, 590 J5222875B0010S
Q1052 00D9630120704 TR KRA102S 1610, 1620, 590 J520010200210S
D1000,1001 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D1002 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D1003-1006 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1021 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D1024,1025 00D9600197107 D,RECTIFIER BRIDGE KBPC604 K047604000020S
