Denon AVR-1708 Service Manual

151
AVR-1708/1508/688/588/488 AVC-1508
AVR-688 E3 model
INPUT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC700 00D 963 0366 304 IC R2A15215FP J084152150010S
IC702 00D 963 0024 004 IC NJM2068M J121206800020S
IC705-718 00D 963 0024 004 IC NJM2068M J121206800020S
Q700,701 00D 960 0196 807 TR 2SK117Y J5441170Y0050S
Q702 00D 963 0120 704 TR KRA102S J520010200210S
Q703 00D 960 0285 006 TR KRC104S J522104S00210S
D700,701 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
ZD700,701 00D 960 0222 603 D,ZENER MTZJ7.5A K06007R544530S
RESISTORS GROUP
R706-709 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R791VC nsp R,METAL FILM 120-J,1W C060012165060S
R791VE nsp R,METAL FILM 120-J,1W C060012165060S
CAPACITORS GROUP
C700 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C702SW 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C703C nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C703SW nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C704,705 00D 963 9005 875 C,ELECT 47UF-M/25V D040470084070S
C706FL 00D 963 9005 875 C,ELECT 47UF-M/25V D040470084070S
C706FR 00D 963 9005 875 C,ELECT 47UF-M/25V D040470084070S
C707FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C707FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C707SW 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C708FL nsp C,CERAMIC 33PF-J/50V D010330167160S
C708FR nsp C,CERAMIC 33PF-J/50V D010330167160S
C708SW nsp C,CERAMIC 47PF-J/50V D010470167160S
C709FL nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C709FR nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C709SW nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C710 00D 963 0223 009 R,THICK 0-J,1/16W C20000006M160S
C710FL nsp C,CERAMIC 100PF-J/50V D010101167160S
C710FR nsp C,CERAMIC 100PF-J/50V D010101167160S
C710SW nsp C,CERAMIC 100PF-J/50V D010101167160S
C711 00D 963 0223 009 R,THICK 0-J,1/16W C20000006M160S
C711FL nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C711FR nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C711SW nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C712 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C713-715 00D 963 0223 009 R,THICK 0-J,1/16W C20000006M160S
C716-727 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C728-731 nsp C,CERAMIC 20PF-J/50V D010200167160S
C732-739 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C740-751 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751A 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751B 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751D 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
