Denon AVR-1708 Service Manual

335
AVR-1708/1508/688/588/488 AVC-1508
PARTS LIST OF EXPLODED VIEW d
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replace-
ment parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
AVR1708E3 : U.S.A. & Canada model AVR1708E2 : Europe model AVR688E3 : U.S.A. & Canada model
AVR1508E3 : U.S.A. & Canada model AVR1508E2 : Europe model AVR1508EUT : Taiwan R.O.C. model
AVR588E3 : U.S.A. & Canada model AVR 488E3 : U.S.A. & Canada model
AVC1508JP : Japan model
Black : Black model
Premium Silver
: Premium Silver model
Silver
: Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
57A nsp POWER P.W.B. ASSY AVR1708E3
7025HK0705013
1*
57A nsp POWER P.W.B. ASSY AVR688E3
7025HK0705023
1*
57A nsp POWER P.W.B. ASSY AVR1708E2
7025HK0705033
1*
57A nsp POWER P.W.B. ASSY AVR1508E3
7025HK0704023
1*
57A nsp POWER P.W.B. ASSY AVR588E3
7025HK0704033
1*
57A nsp POWER P.W.B. ASSY AVR1508E2
7025HK0704043
1*
57A nsp POWER P.W.B. ASSY AVR1508EUT
7025HK0704053
1*
57A nsp POWER P.W.B. ASSY AVC1508JP
7025HK0704063
1*
57A nsp POWER P.W.B. ASSY AVR488E3
7025HK0704013
1*
26 GUIDE L
30 GUIDE R
56 POWER SUPPLY ASSY
57 POWER ASSY
11A nsp FRONT P.W.B. ASSY AVR1708E3
7025HK0705011
1*
11A nsp FRONT P.W.B. ASSY AVR688E3
7025HK0705021
1*
11A nsp FRONT P.W.B. ASSY AVR1708E2
7025HK0705031
1*
11A nsp FRONT P.W.B. ASSY AVR1508E3
7025HK0704021
1*
11A nsp FRONT P.W.B. ASSY AVR588E3
7025HK0704031
1*
11A nsp FRONT P.W.B. ASSY AVR1508E2
7025HK0704041
1*
11A nsp FRONT P.W.B. ASSY AVR1508EUT
7025HK0704051
1*
11A nsp FRONT P.W.B. ASSY AVC1508JP
7025HK0704061
1*
11A nsp FRONT P.W.B. ASSY AVR488E3
7025HK0704011
1*
9 POWER SW ASSY
10 FUNCTION ASSY
11 FRONT ASSY
14 HEAD PHONE ASSY
21 V- AUX ASSY
22 MIC ASSY
except for AVR1508E3/
AVR1508EUT/AVR588E3/
AVC488E3
55 SPEAKER ASSY
50A nsp MAIN P.W.B ASSY AVR1708E3
7025HK0705010
1*
50A nsp MAIN P.W.B ASSY AVR688E3
7025HK0705020
1*
50A nsp MAIN P.W.B ASSY AVR1708E2
7025HK0705030
1*
50A nsp MAIN P.W.B ASSY AVR1508E3
7025HK0704020
1*
50A nsp MAIN P.W.B ASSY AVR588E3
7025HK0704030
1*
50A nsp MAIN P.W.B ASSY AVR1508E2
7025HK0704040
1*
50A nsp MAIN P.W.B ASSY AVR1508EUT
7025HK0704050
1*
50A nsp MAIN P.W.B ASSY AVC1508JP
7025HK0704060
1*
50A nsp MAIN P.W.B ASSY AVR488E3
7025HK0704010
1*
50 P.C.B MAIN ASSY

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
