Denon AVR-1708 Service Manual

247
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
HDMI P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC01 nsp SII9185CTU 00D2623721007
IC03 nsp IC SE1117-1.8 J126111718010S
IC12 nsp IC BU4094BCF-E2 J040140940030S
IC801 nsp ADSP21367KSZ1A1136 00D2623709016
IC802 nsp W9864G2GH-7 00D2623746008
IC803 nsp IC EN29LV160T-70TCP J005291600010S
IC807 nsp LC89057W-VF4A 00D2623449004
IC808 nsp ADAU1328BSTZ1136 00D2623645015
IC809-811 nsp IC SN74LVC244APWR J040742440230S
IC812 nsp IC SN74HCT244PWR J040742440220S
IC814,815 nsp IC SN74HCT00PWR J040740000210S
IC816 nsp 74LVX157MTC +C 00D2622870904
IC823 nsp IC KIA7805API J126780500110S
IC825,826 nsp IC SN74LVC74APWR J040747400200S
IC832 nsp IC SE1117-33-PF J126111733020S
Q01,02 nsp TR KRC102S J522010200210S
Q03,04 nsp TR KRC104S J522104S00210S
Q05 nsp TR KRA102S J520010200210S
Q06 nsp TR KTC3875S J522038750210S
Q07 nsp TR KRC104S J522104S00210S
Q810D nsp TR KRC102S J522010200210S
Q811D nsp TR KRA102S J520010200210S
Q814D nsp TR KRA102S J520010200210S
D01-36 nsp D,ESD IMSA-6802-01A K067680200010S
D44 nsp D,SWITCHING KDS4148U K005041480030S
CAPACITORS GROUP
C01 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C02-05 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C06,07 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C08-14 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C15-17 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C18,19 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C20 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C21 nsp C,CERAMIC 100PF-J/50V D010101167160S
C22 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C23 nsp C,CERAMIC 100PF-J/50V D010101167160S
C24,25 nsp C,ELECT 10UF-MVG/16V D050100083460S
C26,27 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C28H nsp C,ELECT 10UF-MVG/16V D050100083460S
C29 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C29H nsp C,ELECT 10UF-MVG/16V D050100083460S
C30 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C30H nsp C,ELECT 10UF-MVG/16V D050100083460S
C31,32 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C63-65 nsp C,CERAMIC 100PF-J/50V D010101167160S
C66 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C831D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C832D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C833D nsp C,CERAMIC 100PF-J/50V D011101167101S
C834D nsp C,CERAMIC 100PF-J/50V D011101167101S

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
