Denon AVR-1708 Service Manual

184
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 E3 model
CP511 nsp CN.WAFER 9P L101220090000S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
CP514 nsp CN.WAFER 13P L101220130000S
z F501 00D 963 0236 106 FUSE T8A /250V N751228001110S
F501A nsp HOLDER,FUSE CLIP G645000050010S
F501B nsp HOLDER,FUSE CLIP G645000050010S
z F503 00D 963 0236 106 FUSE T8A /250V N751228001110S
F503A nsp HOLDER,FUSE CLIP G645000050010S
F503B nsp HOLDER,FUSE CLIP G645000050010S
GND501 nsp TERMINAL EARTH 3790040886000S
RLY501 963682000640S RELAY HL3-1A-6SH G680060102020S
z SUB501 00D 963 0382 704 SUB TRANS 8200280150400S
nsp HEAT SINK 2120043538050S
nsp HEAT SINK 2120044298010S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH B020030081B10S
00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
z 00D 203 3976 002 SOCKET,POWER RECEPTA G435204004010S
Ref. No. Part No. Part Name Remarks Q'ty New
h

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
