Denon AVR-1708 Service Manual

240
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
2CH-AMP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401D 00D 960 0159 501 IC KIA7805API J126780500110S
IC401H 00D 963 0388 805 CN,WIRE 110MM/3P L000111030040S
IC402D 00D 963 0226 608 IC KIA78R33PI J12678R330010S
IC402X 00D 963 0366 603 IC KIA1117PI50 J126111750050S
IC403D 00D 963 0366 706 IC KIA1117PI00 J126111700050S
Q401SBL 00D 996 0018 706 TR 2SD2390-Y J5032390Y0000S
Q401SBR 00D 996 0018 706 TR 2SD2390-Y J5032390Y0000S
Q402D 00D 960 0097 304 TR KRC102M J6020102M0010S
Q402SBL 00D 996 0018 706 TR 2SD2390-Y J5011560Y0000S
Q402SBR 00D 996 0018 706 TR 2SD2390-Y J5011560Y0000S
Q403SBL 00D 963 0280 107 TR 2SC3964 J502396400000S
Q403SBR 00D 963 0280 107 TR 2SC3964 J502396400000S
Q404SBL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q404SBR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q405SBL 00D 273 0459 903 TR KTC2874B J502287400010S
Q405SBR 00D 273 0459 903 TR KTC2874B J502287400010S
Q406SBL 00D 960 0196 205 TR KSA992F J5000992F0050S
Q406SBR 00D 960 0196 205 TR KSA992F J5000992F0050S
Q407SBL 00D 960 0196 205 TR KSA992F J5000992F0050S
Q407SBR 00D 960 0196 205 TR KSA992F J5000992F0050S
Q408SBL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q408SBR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q409D 00D 960 0097 304 TR KRC102M J6020102M0010S
D401H 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D401SBL 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D401SBR 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D401X 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
D402H 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402SBL 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D402SBR 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D402X 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D403 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
ZD401D 00D 960 0095 607 D,ZENER MTZJ5.6B K06005R644520S
ZD401SBL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ S K06603R34P400S
ZD401SBR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ S K06603R34P400S
ZD402SBL 00D 963 0367 008 D,ZENER 0.2W 3.0V UDZ S K06603R04P400S
ZD402SBR 00D 963 0367 008 D,ZENER 0.2W 3.0V UDZ S K06603R04P400S
RESISTORS GROUP
R401D 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R401H 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R401X 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402D 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402H 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402X 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R410SBL 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R410SBR 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R411SBL 00D 960 9010 719 R,METAL FILM 47-J,1W C060047065060S
R411SBR 00D 960 9010 719 R,METAL FILM 47-J,1W C060047065060S

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
