Denon AVR-1708 Service Manual

295
AVR-1708/1508/688/588/488 AVC-1508
AVR-488 E3 model
CPU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC713-715 00D 963 0024 004 IC NJM2068M J121206800020S
IC804 963243000020D IC,CPU MICRO PROCESS
M30626FHPFP 8952150800015
IC806 00D 960 0100 301 IC KIA7812API J126781200040S
IC813 00D 963 0367 204 IC SN74HC151PWR J040741510070S
IC817 00D 963 0244 907 IC SN74LV14APWR J040741400180S
IC818 00D 963 0367 307 IC SN74AHCU04PWR J040740400290S
IC824 00D 963 0043 807 IC BA4510F-E2/SOP8 J121451000010S
IC827 00D 963 0043 807 IC BA4510F-E2/SOP8 J121451000010S
IC830 00D 262 2813 903 SN74AHCT08PW-EL2 +C J040740800190S
Q704C 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q704FL 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q704FR 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q704SL 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q704SR 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q704SW 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q801 00D 963 0120 704 TR KRA102S J520010200210S
Q802-805 00D 963 0044 301 TR KTC2875B(MB) J5222875B0010S
Q806 00D 963 0121 509 TR KTC3875S J522038750210S
Q807 00D 960 0285 006 TR KRC104S J522104S00210S
Q810D 00D 963 0245 100 D,SWITCHING KDS226ST1(C3) K005022600020S
Q811D 00D 963 0245 100 D,SWITCHING KDS226ST1(C3) K005022600020S
Q812D 00D 963 0120 801 TR KRC102S J522010200210S
Q813D 00D 963 0120 704 TR KRA102S J520010200210S
D801-804 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D805 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D807 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D807D 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D808D 00D 963 0341 305 D,ESD IMSA-6802-01A K067680200010S
D809D 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D810D 00D 963 0341 305 D,ESD IMSA-6802-01A K067680200010S
D811D 00D 963 0341 305 D,ESD IMSA-6802-01A K067680200010S
ZD801 00D 963 0047 502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R857 00D 960 9003 807 R,METAL 100-J,1/4W C060010163050S
CAPACITORS GROUP
C751C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751SW 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C752C 00D 963 0350 503 C,CERAMIC 390PF-J/50V D010391167160S
C752FL 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C752FR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C752SL 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SR 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SW 00D 963 0350 503 C,CERAMIC 390PF-J/50V D010391167160S
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
WhenupdateFirmware,please
confirmalastversioninSDI.
Usetheserviceboardafter
updatingit.
