PCB FRONT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC100 00D2631289900 IC AZ4580M J121458000020S
IC102 00D2631289900 IC AZ4580M J121458000020S
Q100,101 943214500020S TR 2SC 2SC3052 CVT2SC3052
Q102 00D9600133103 TR 2SA KSA916Y J5000916Y0050S
Q106 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q107,108 963212500030S TR 2SA ISA1530AC1 J520015301210S *
Q109 943215500030S TR 2SA RT1P441C CVTRT1P441C
Q111,112 943216500020S TR 2SC RT1N141C CVTRT1N141C
D100,101 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D102,103 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D111-114 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D115,116 963209003510S D,ESD CDS3C05HDMI1
2112CIE3,1912E2,
1912EA,1912E1C
K067030500010S
D117 963209500020S D,ESD CDS3C15GTA
2112CIE3,1912E2,
1912EA,1912E1C
K067031500010S *
D118,119 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D123,124 963209003510S D,ESD CDS3C05HDMI1 1912E3 K067030500010S
D125 963209500020S D,ESD CDS3C15GTA 1912E3 K067031500010S *
ZD100 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD101 00D9600095801 D,ZENER MTZJ6.8B K06006R844520S
ZD102 00D9630046202 D,ZENER MTZJ18B K06018R044520S
ZD103 00D2760665903 D,ZENER MTZJ16B K06016R044520S
ZD104,105 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
LED101 963262010460S LED SIR-341ST3F 3PI 2112CIE3 K505341300010S
LED103 00D9630366108 LED BL-BEG204-L 5PI
2112CIE3,1912E2,
1912EA,1912E1C
K500052004010S
LED104 00D9630366108 LED BL-BEG204-L 5PI 1912E3 K500052004010S
RESISTORS GROUP
R127 00D9639006272 R,FIXED RSD-R1-1WJ-4.7 N113135647920S
CAPACITORS GROUP
C100 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C101 nsp C,FILM 0.1UF-J/100V D02010406C060S
C103 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C104 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C105 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C106 nsp C,CERAMIC 100PF-J/50V D010101167160S
C107 nsp C,CERAMIC COG82PF-J/50V D010820167160S
C108 nsp C,FILM 0.047UF-J/100V D02047306C060S
C109 nsp C,FILM 0.1UF-J/100V D02010406C060S
C110 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C111 nsp C,CERAMIC 1UF-Z/50V D011105597160S
C112 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C113 nsp C,FILM 0.1UF-K/250V D02010407H080S
C114 nsp C,CERAMIC 330PF-J/50V D010331167160S
C115 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C116 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C117 nsp C,ELECT 470UF-M/63V D040471088010S
C118 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C119 nsp C,FILM 0.1UF-K/250V D02010407H080S
C120 nsp C,CERAMIC 330PF-J/50V D010331167160S
C121 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C122 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C123 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C124-126 nsp C,CERAMIC 100PF-J/50V D010101167160S
C127 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C129 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
