4. DIAGNOSTICMODE(Video/Audio(signal)pathconrmationmode)
This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting)
Conrming the operation of unit can be easily done after repair.
Backup data will not be lost.
4.1. Starting diagnostic mode
Press the ON/STANDBY button to turn on the power while pressing both the "PRESET CHANNEL1" button and the "STATUS" button at the same time.
d
Q1, Q2 and Q3 are lit in FL display.
4.2. Canceling diagnostic mode
Turn off the power by pressing the ON/Standby button.
4.3. Operation
When you perform remote operation in accordance with the instructions in "Details of how to operate remote controller" *a) in the table below using the remote control unit (RC-1156).
You will nd using another remote control unit with the macro functions very useful. To use the macro functions, program a macro function to output a remote control code in accordance with the steps in *b) in the table below.
3.4. Videosystemconrmationitems
g.XX : Refer to the block diagram of the g.XXth.
Conrmationitem Setting and display Details of how to operate remote controller *a)
Output sequence of remote control codes
※
It is useful to form a macro program. *b)
Contentsofconrmation Remarks
1
Analog Video (signal) Path All ZONE : ON
Display:
V 0 1 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : CVBS / Output : CVBS
·Input : S / Output : CVBS
4.Press [ZONE SELECT], Select "MAIN"
5.Press [1/./]
w
KEY 1/CODE1 (Main Zone)
Initialization
6.Press [ZONE SELECT], Select "ZONE2"
7.Press [ZONE ON]
e
ZONE2 POWER ON
8.Press [ZONE SELECT], Select "MAIN"
9.Press [DVD]
r
DVD (Main Zone)
2
Analog or HDMI to HDMI (signal) Path Display:
V 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input CVBS / Output : HDMI
·Input S-VIDEO / Output : HDMI
·Input Component / Output : HDMI
·Input HDMI / Output : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
Conrm the input pass one by one.
Because it becomes only the input of the highest input
becomes Convert/ (signal) Path if it inputs it at the same
time.
(HDMI input > Component input > S-VIDEO input >
CVBS input)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [2/ABC]
w
KEY 2/ABC (Main Zone)
Initialization
6.Press [DVD]
e
DVD (Main Zone)
3
OSD FUNCTION Menu : ON
All ZONE :ON
Display:
V 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·OSD Display / Output : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [2/ABC]
w
KEY 2/ABC (Main Zone)
Initialization
6.Press [ZONE SELECT], Select "ZONE2"
7.Press [ZONE ON]
e
ZONE2 POWER ON
8.Press [ZONE SELECT], Select "MAIN"
9.Press [DVD]
r
DVD (Main Zone)
10.Press [AMP]
11.Press [MENU]
t
GUI MENU (Main Zone)
4
CEC FUNCTION
(Control Monitor : HDMI Monitor)
HDMI Control : ON
Display:
V 0 3 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF · When the power supply of a TV is put in the standby mode, make sure
that the power supply of this unit is also put in the standby mode.
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [3/DEF]
w
KEY 3/DEF (Main Zone)
Initialization & CEC Control ON
6.Press [DVD]
e
DVD (Main Zone)
5
HDMI Audio (signal) Path
(Audio : AMP)
Audio : AMP(When checking the audio output
from AMP)
Display:
V 0 5 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : HDMI (Signal of PCM, DolbyDigital or DTS) / Output : Speakers
·Input : HDMI (Signal of HD Audio) / Output : Speakers
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [5/JKL]
w
KEY 5/JKL (Main Zone)
Initialization & Select Audio AMP
6.Press [DVD]
e
DVD (Main Zone)
6
HDMI Audio (signal) Path
(Audio : TV)
Audio : TV(When checking the audio output
from TV)
Display:
V 0 6 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF · Input : HDMI (Signal of PCM or DolbyDigital or DTS) / Output : HDMI
(Audio output from connected TV)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [6/MNO]
w
KEY 6/MNO (Main Zone)
Initialization & Audio Select TV
6.Press [DVD]
e
DVD (Main Zone)
g.1
g.2
g.3
g.4
g.5
g.6
27
